Intercomp CS1500 Industrial Crane Scale

Intercomp CS1500 Industrial Crane Scale

With a large, easy-to-read LED display, the lineup of Intercomp CS1500 industrial crane scales are available in capacities up to 10,000 pounds, are NTEP certified, and offer best-in-class battery life. The scale comes standard with RFX® Wireless Weighing Technology enabling cable-free control & monitoring of scales. Also featured are USB/RS232 output, multi-scale communication, & a multitude of remote display options.

RFQ

Call: (919) 776-7737

Features:

  • Accuracy of ±0.1% of Reading
  • NTEP Certified Models Available
  • Available in Capacities up to 10,000 lb (5,000 kg)
  • Large, Easy-to-Read, LED Display
  • Commercially Available D-Cell Batteries Last up to 500 Hours in Scale

Intercomp CS1500 Crane Scales

With a large, easy-to-read LED display, CS1500™ high performance crane scales are available in capacities up to 10,000 lb (5,000 kg), are NTEP certified, and boast best-in-class battery life. The scale comes standard with RFX® Wireless Weighing Technology enabling cable-free control and monitoring of scales. Also featured are USB/RS232 output, multi-scale communication, and a multitude of remote display options. NTEP Certified Models Available (CoC# 97-135A4)





ITEM # ........ DESCRIPTION
184516-RFX   CS1500 CRANE SCALE W/LED & REMOTE (2K X 1) NTEP CLASS III 2,000 X 1 LB (1,000 X .5 KG)

184517-RFX   CS1500 CRANE SCALE W/LED & REMOTE (5K X 2) NTEP CLASS IIIL 5,000 X 2 LB (2,500 X 1 KG)

184518-RFX   CS1500 CRANE SCALE W/LED & REMOTE (10K X 5) NTEP CLASS IIIL 10,000 X 5 LB (5,000 X 2 KG)







Accessories/Options
101231  CABLE, CS750/CS1500/CS3000 TO THERMAL PRINTER (15'/4.5 M). OPTION 184507 REQUIRED

101233  CABLE, SERIAL OUTPUT CS750/CS1500/CS3000 TO RS232/USB (15'/4.5 M). OPTION 184507 REQUIRED

184506  RS232/DIRECT POWER CONNECTOR (184507) W/COILED POWER CORD & 120V/220V WALL MOUNT AC/DC ADAPTER

184507  RS232/DIRECT POWER CONNECTOR FOR CS1500/CS3000 (MUST BE ORDERED W/SCALES), CABLES SOLD SEPARATELY

330112-CS  BATTERY PACK 2 X 4 D-CELL NIMH

100858  EXTERNAL BATTERY CHARGER FOR 2 X 4 D PACK (120 V/220 V)

750501  CERTIFICATE OF CALIBRATION

























Old Part Numbers for Reference

Part Number .......... Description ................ Capacity x Readability ........ Item Weight
184500-RFX ........... LCD with Remote ................. 500 x 0.2 lb ...................... 29 lb
184501-RFX ........... LCD with Remote .............. 1,000 x 0.5 lb ...................... 29 lb
184502-RFX ........... LCD with Remote .............. 2,000 x 1 lb ......................... 29 lb
184503-RFX ........... LCD with Remote .............. 5,000 x 2 lb ......................... 50 lb
184504-RFX ........... LCD with Remote ............. 10,000 x 5 lb ........................ 50 lb
184505-RFX ........... LCD with Remote ............. 20,000 x 10 lb ...................... 91 lb



Part Number .......... Description ................ Capacity x Readability ........ Item Weight
184514-RFX ........... LED with Remote ................. 500 x 0.2 lb ...................... 29 lb
184515-RFX ........... LED with Remote .............. 1,000 x 0.5 lb ...................... 29 lb
184516-RFX ........... LED with Remote .............. 2,000 x 1 lb ......................... 29 lb
184517-RFX ........... LED with Remote .............. 5,000 x 2 lb ......................... 50 lb
184518-RFX ........... LED with Remote ............. 10,000 x 5 lb ........................ 50 lb
184519-RFX ........... LED with Remote ............. 20,000 x 10 lb ...................... 91 lb

750501 ......... Certificate of Calibration
101225-RFX ..  Handheld Weight Indicator
100799 .........  RS232 Serial output (must be ordered with scale)
100858 .........  Charger External 120/220v for 2 x 4 D Size Battery Stick (NiCad/NiMH)
101055 .........  Cable, Direct Power 10 ft
330112-CS ..... Battery Pack
101233 ........... Cable, serial output 15 ft
101231 ........... Printer Cable


Part Number ....... Description .............. Capacity x Readability ........
100661 ............... LED with Remote ................ 500 x 0.2 lb .........
100662 ............... LED with Remote .............. 1,000 x 0.5 lb .........
100663 ............... LED with Remote .............. 2,000 x 1 lb ............
100664 ............... LED with Remote .............. 5,000 x 2 lb ...........
100665 ............... LED with Remote ............. 10,000 x 5 lb ...........
100666 ............... LED with Remote ............. 20,000 x 10 lb .........
