Brecknell DCSB Pegasus Floor Scale

Brecknell DCSB Pegasus IP65 rated mild general purpose industrial floor scale with alloy tool steel potted load cells. Legal for Trade, NTEP certified at 5,000 divisions. Choices of sizes and capacities.

RFQ

Call: (919) 776-7737

Share on Facebook

The Brecknell DCSB Pegasus industrial floor scale is a great choice if you're looking to purchase an affordable platform scale that is reliable and constructed to handle the warehouse environment. Brecknell is a division of Avery Weigh-Tronix, which manufacturers some of the best digital scales in the world, so you can rest assured you are purchasing high quality weighing equipment.



BRECKNELL DCSB FLOOR SCALE FEATURES

Rugged Construction– Up to 6 mm / 0.25" thick top plate with heavy duty welded channel support
Legal for Trade– All sizes are NTEP certified at 5,000 divisions
Low Profile– 91 cm / 3.1 inches high; 44 mm / 1.75" adjustable leveling feet
Finish– Powder coat paint
Versatile– Pit mounted or free standing
Load Cells– Four alloy tool steel potted
Painted Mild Steel Construction
Certifications: NTEP COC #02-070



salter brecknell dcsb pegasus industrial floor scale weighing a loaded pallet

Part Number ......... Model ........................ Dimensions / Capacity .............................. Ship Weight
56973-0013          DCSB3636-02       914 mm / 36", 1000 kg x 0.2 kg / 2000 lb x 0.5 lb       77 kg / 170 lb
56977-0019          DCSB4848-05       1219 mm / 48", 2500 kg x 0.5 kg / 5000 lb x 1 lb        120 kg / 265 lb
56978-0018          DCSB6060-05       1524 mm / 60", 2500 kg x 0.5 kg / 5000 lb x 1 lb        204 kg / 450 lb
56977-0209          DCSB4848-10       1219 mm / 48", 5000 kg x 1kg / 10,000 lb x 2 lb         122 kg / 269 lb
56978-0208          DCSB6060-10       1524 mm / 60", 5000 kg x 2 kg / 10,000 lb x 2 lb        208 kg / 460 lb



DCSB Related Options
60132-0013   J-Box pig-tail cable (0.3mm / 1' length)
60132-1011   SS Indicator Interface Cable assy. (4.5 m / 15')



Options
Ramps: Up to four ramps can be used with the Pegasus family
Indicators: The Pegasus can be used with a variety of electronic weight indicators that we offer
Calibration: We can connect and calibrate the weight indicator to the DCSB floor scale
Pit Frames: Mild steel frames
Indicator Stand: 48" high, mild steel, powder coat painted, for the Brecknell indicator. Includes stand, mounting hardware, baseplate



Ramp End - Includes two straight ramp brackets
52775-0012   914 mm / 36", 1000/2500 / 2000/5000 lb
52775-0020   1219/914 mm / 48/36", 2500/5000 kg / 5000/10,000 lb
52775-0061   1219 mm / 48', 2500/500 kg / 5000/10,000 lb
52775-0038   1524/914 mm / 60/36", 2500/5000 kg / 5000/10,000 lb



Pit Frame
41180-0022   914 mm / 36", 1000/2500 kg / 2000/5000 lb
41180-0030   1219 mm / 48", 2500/5000 kg / 5000/10,000 lb
41180-0055   1219/1524 mm / 48/60", 2500/500 kg / 5000/10,000 lb
41180-0105   1219/1828 mm / 48/73", 2500/500 kg / 5000/10,000 lb
41180-0071   1524 mm /60", 2500/5000 kg / 5000/10,000 lb
