Rinstrum’s axleWEIGHr is a fast, accurate and economical way to monitor commodities that are coming into or leaving your facilities, and improve load capacity and safety. Drive over the scale while moving a constant 2-3 mph. The scale will automatically weigh each axle and can print a receipt with individual axle weights and the total GVWR ideal for CoR requirements. If you store the trucks ID and tare weight, or use 2 pass weigh in weigh out weighing, the controller will calculate the Gross, Tare and Net values.
On average better than ± 0.5% accuracy can be expected. Company testing as well as extensive field trials have shown that with extended flat and level concrete approaches ± 0.2% or better accuracy can be achieved on average. Individual results may vary. Well maintained vehicles weigh the best.
The axleWEIGHr weigh in motion scale has been developed over a period of time with the assistance of Southern Illinois Scale leveraging their specialist knowledge in heavy capacity scales. Rinstrum has been designing and manufacturing industrial weighing electronics for over 30 years and working specifically on in motion scales for over 20 years. axleWEIGHr scales are manufactured in Noble, Illinois and combined with a Rinstrum measurement chain for installation across the USA and beyond. With over 180 scales installed across the USA and Australia, we are proud to be able to provide an economical accurate weigh in motion scale to our customers so they can readily know their truck axle weights.
